Engine- Vortec 4.8L V8 SFI (285 hp [212.5 kW] @ 5400 rpm- 295 lb-ft of torque [398.3 N-m] @ 4600 rpm) (Includes external engine oil cooler. Reference the Engine/Axle page for availability.)
Rear axle- 3.42 ratio (Reference the Engine/Axle page for availability.)
Body- standard
GVWR- 8600 lbs. (3901 kg) (Reference the Engine/Axle page for availability.)
Transmission oil cooler- external (Deleted when (LWN) 2.8L Duramax Turbo Diesel engine is ordered.)
Rear wheel drive
Battery- 600 cold-cranking amps- maintenance-free with rundown protection and retained accessory power
Alternator- 105 amps (Not available with (Y3H) Paratransit Package or (LWN) 2.8L Duramax Turbo Diesel engine.)
Frame- full-length box ladder-type
Suspension- front independent with coil springs and stabilizer bar
Suspension- rear hypoid drive axle with multi-leaf springs
Steering- power
Brakes- 4-wheel antilock- 4-wheel disc
Fuel tank capacity- mid-frame and approximately 31 gallons (117.3L)
Exhaust- aluminized stainless-steel muffler and tailpipe
Door- swing-out passenger-side- 60/40 split
Tires- front LT245/75R16E all-season- blackwall
Tires- rear LT245/75R16E all-season- blackwall
Bumpers- front and rear painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Grille- Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
Headlamps- single halogen (Not available with (ZR7) Chrome Appearance Package.)
Mirrors- outside manual- Black
Glass- Solar-Ray light-tinted- all windows
Wipers- front intermittent wet-arm with pulse washers
License plate kit- front
Console- engine cover with open storage bin
Floor covering- full-length Black rubberized-vinyl (Not available with (RFM) rear floor covering delete- (5BV) Upfitter electrical or (PCH) Hotel Shuttle Package.)
Steering wheel- steel sleeve column with theft-deterrent locking feature- Black
Instrumentation- analog with speedometer- odometer with trip odometer- fuel level- voltmeter- engine temperature and oil pressure
Oil life monitor
Warning tones- headlamp on and key-in-ignition
Theft-deterrent system- vehicle- PASS-Key III
Defogger- side windows
Cup holders- 3 on the engine console cover
Trim panels- hinged rear side doors and hinged rear doors (Not available with (Y3H) Paratransit Package.)
Headliner- cloth- over driver and passenger
Visors- driver and front passenger- cloth- padded
Assist handles- driver and right-front passenger
Lighting- interior with 4 dome lights 1 overhead and 3 LED's on cross members in cargo area- includes defeat switch and door handle-activated switches
Cargo tie-downs 6 D-ring attachments on cargo area floor (Not available with (Y3H) Paratransit Package- (5BV) Upfitter electrical provisions- (5L3) interior trim panel or (ZP6) 5-passenger Express Crew Van.)
Brake/transmission shift interlock- for automatic transmissions
StabiliTrak- traction assistance and vehicle stability enhancement system
Door beams- steel-side
Daytime Running Lamps
Air bags- driver and right-front passenger- seat-mounted side-impact and head curtain side-impact (Always use safety belts and the correct child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
