Engine- Vortec 4.3L V6 MFI (195 hp [145.4 kW] @ 4600 rpm- 260 lb-ft of torque [351.0 N-m] @ 2800 rpm) (Standard and only available on CG13405 model. Reference the Engine/Axle page for availability.)
Rear axle- 3.42 ratio (Standard on CG13405- CH13405- CG23405- CG23705- CG33405 and CG33705 models. Required with (LU3) Vortec 4.3L V6 MFI engine- (L20) Vortec 4.8L V8 SFI engine- (L96) Vortec 6.0L V8 SFI FlexFuel or (LC8) Gaseous 6.0L V8 SFI engine. Available with (LMF) Vortec 5.3L V8 SFI FlexFuel engine. Reference the Engine/Axle page for availability.)
Body- standard
Rear wheel drive
Battery- 600 cold-cranking amps- maintenance-free with rundown protection and retained accessory power
Frame- full-length box ladder-type
GVWR- 7300 lbs. (3311 kg) (Standard on CG13405 or CH13405 models. Reference the Engine/Axle page for availability.)
Suspension- front independent with coil springs and stabilizer bar (Requires CG13405- CG23405- CG23705- CG33405 and CG33705 models.)
Suspension- rear hypoid drive axle with multi-leaf springs
Steering- power
Brakes- 4-wheel antilock- 4-wheel disc
Fuel tank capacity- mid-frame and approximately 31 gallons (117.3L)
Exhaust- aluminized stainless-steel muffler and tailpipe
Door- swing-out passenger-side- 60/40 split
Bumpers- front and rear painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Grille- Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
Headlamps- single halogen (Not available with (ZR7) Chrome Appearance Package.)
Mirrors- outside manual- Black
Glass- Solar-Ray light-tinted- all windows
Wipers- front intermittent wet-arm with pulse washers
License plate kit- front
Audio system- radio provisions only. Includes alarm warning chimes- radio wiring harness- radio antenna and 2 front door speakers
Console- engine cover with open storage bin
Floor covering- full-length Black rubberized-vinyl (Not available with (YF2) Ambulance Package or (RFM) rear floor covering delete.)
Steering wheel- steel sleeve column with theft-deterrent locking feature- Black
Instrumentation- analog with speedometer- odometer with trip odometer- fuel level- voltmeter- engine temperature and oil pressure
Oil life monitor
Warning tones- headlamp on and key-in-ignition
Compass- 8-point digital located in the Driver Information Center (Included and only available with (TR9) auxiliary lighting.)
Theft-deterrent system- vehicle- PASS-Key III
Defogger- side windows
Cup holders- 3 on the engine console cover
Trim panels- hinged rear side doors and hinged rear doors
Headliner- cloth- over driver and passenger
Visors- driver and front passenger- cloth- padded
Assist handle- front passenger
Lighting- interior with 2 dome lights- defeat switch and door handle-activated switches
Lighting- auxiliary with reading and underhood lights (Standard on CG13405 and CH13405 models. Includes (U80) 8-point digital compass. Included with (PCR) Express Access Plus Package or (ZP6) Express Crew Van Package when ordered with CG23705 or CG33705 models. Not available with (YF2) Ambulance Package.)
Brake/transmission shift interlock- for automatic transmissions
StabiliTrak- traction assistance and vehicle stability enhancement system
Door beams- steel-side
Daytime Running Lamps
Air bags- frontal- driver and right-front passenger (Includes passenger-side air bag deactivation switch on models CG23405- CG23705- CG33405 and CG33705. Not available with (ZX1) driver only high-back bucket seat or (AJ3) driver-side only frontal air bag. Always use safety belts and the correct child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Air bags- head/side-curtain (Standard on CG13405 and CH13405 models. Requires (AK5) driver and right-front passenger air bags and (TR9) auxiliary lighting. (TR9) auxiliary lighting is not required if (ZP6) 5-passenger- Express Crew Van Package seating arrangement is ordered. Not available with (AJ3) driver-side only frontal air bag and SEO option (5L3) interior trim panels. Always use safety belts and the correct child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
